Maximum efficiency at minimum costs
Maximize machine and battery uptime with continuous, reliable monitoring and smart optimization. Protect your battery investment from common operator errors like low electrolyte levels and deep discharge. A simple LED traffic light display and intuitive, icon-based LCD interface guide users of all experience levels to extend battery life and keep operations running smoothly.
Enhance battery life time and fleet uptime.
Get the most from your fleet with continuous monitoring and optimization. Motion+ EasyMonitor provides full battery transparency—track cycle life, voltage, temperature, and electrolyte levels. Simplify rental and warranty management with accurate usage data and avoid disputes by knowing the exact battery condition at all times.
Secure profit with Easy 1-Click-Installation.
Boost profits with just one click. Motion+ EasyMonitor starts working instantly—just wrap the probe around a cell connector to monitor electrolyte level, temperature, and voltage symmetry. Its 3-in-1 sensor and double-protected design ensure safety and fast ROI, while helping extend battery life and reduce total cost of ownership.
Technical data
Feature |
|
|---|---|
Voltage range |
max. 60 mA at 18V DC |
Current draw |
18 - 120V |
Current measurement range |
± 3.5 – 1000 A |
Operating temperature range |
-10 to 60 °C |
Permitted storage temp. |
-20 to 60 °C |
Relative humidity |
< 90 % |
Casing |
IP 65 according to EN 60529 |
Dimensions (L x H x W) |
144 x 44 x 20 mm |
Weight |
400 g |
Standards |
2014/35 EU – Low voltage directive |
How it works.
